Sabo

Sabo by Molycop grinding media gives customers around the world the value and quality credentials they need to operate cost-effective and efficient mines.

Make an Enquiry

Product Features

A complete grinding media product range enabling mines to operate efficiently and effectively
Available in nominal ball diameters from 20mm to 125mm or 0.8 inches to 4.9 inches
Meets the criteria for chemical composition, volumetric and surface hardness

Product Overview

Sabo by Molycop products offer quality at great value, with customers benefiting from Molycop’s global expertise and its local sales and service knowledge. And with Molycop’s proven track record in supply chain certainty, Sabo products are delivered on time, every time.

Synonymous with grinding media, Molycop provides Sabo with access to the group’s extensive technical expertise and know-how to deliver a range of forged, high-chrome and ceramic grinding media. Sabo by Molycop grinding media is specified and supplied to stringent criteria for chemical composition, volumetric and surface hardness designed for the Sabo by Molycop range of products.

Simply put, Sabo by Molycop delivers a quality product at great value – providing assurance in product quality and delivery backed by Molycop.

Product Typical Uses

The Sabo by Molycop range is used primarily for grinding media operations that require a quality product at great value.

Product Benefits

Delivery enabled by Molycop’s best-in-class global supply chain network.
Technical support and training utilising Molycop’s global expertise.
Local service in all key mining regions.

Technical Data

Ball Diameter (in)		C		Mn		Si		Cr		Mo.
In.	mm.	Min.	Max.	Min.	Max.	Min.	Max	Min.	Max	Min.	Max
0.8	20	0.7	0.9	0.6	0.9	0.15	0.37	0.2	0.9	0	0.035
1.0	25	0.7	0.9	0.6	0.9	0.15	0.37	0.2	0.9	0	0.035
1.2	30	0.7	0.9	0.6	0.9	0.15	0.37	0.2	0.9	0	0.035
1.6	40	0.7	0.9	0.6	0.9	0.15	0.37	0.2	0.9	0	0.035
2.0	50	0.7	0.9	0.6	0.9	0.15	0.37	0.2	0.9	0	0.035
2.4	60	0.7	0.9	0.6	0.9	0.15	0.37	0.2	0.9	0	0.035
2.8	70	0.7	0.9	0.6	0.9	0.15	0.37	0.2	0.9	0	0.035
3.1	80	0.7	0.9	0.6	0.9	0.15	0.37	0.2	0.9	0	0.035
3.5	90	0.55	0.68	0.4	0.9	1.3	1.9	0.6	0.9	0	0.035
3.9	100	0.55	0.68	0.4	0.9	1.3	1.9	0.6	0.9	0	0.035
4.3	110	0.55	0.68	0.4	0.9	1.3	1.9	0.6	0.9	0	0.035
4.9	125	0.55	0.68	0.4	0.9	1.3	1.9	0.6	0.9	0	0.035
S Max (≤0.035)						P Max (≤0.035)

Inches (in)

0.8	1.0	1.2	1.6	2.0	2.4	2.8	3.1	3.5	3.9	4.3	4.9

Millimeters (mm)


20	25	30	40	50	60	70	80	90	100	110	125

Ball Diameter		Average Surface Hardness		Average Volumentric Hardness
in.	mm.	Min.	Max.	Min.	Max.
0.8	20	60	65	60	65
1.0	25	60	65	60	65
1.2	30	60	65	60	65
1.6	40	60	65	60	65
2.0	50	59	64	59	64
2.4	60	59	64	59	64
2.8	70	59	64	59	64
3.1	80	59	64	59	64
3.5	90	57	63	57	63
3.9	100	56	62	56	62
4.3	110	56	62	56	62
4.9	125	56	62	56	62

Ball Diameter (inch)	Ball Diameter (mm)	Minimum Mass (g)	Maximum Mass (g)
0.8	20	28	44
1.0	25	57	81
1.2	30	100	134
1.6	40	243	304
2.0	50	482	576
2.4	60	821	1025

2.8	70	1318	1594

3.1	80	1983	2344
3.5	90	2842	3298

3.9	100	3859	4612

4.3	110	5165	6074
4.9	125	7630	8801
